IPS Display specifications Display size (diagonal) 60.96 cm (24?)
Panel active area 51.84 x 32.4 cm Aspect ratio 16:10
Native resolution WUXGA (1920 x 1200 @ 60 Hz) (The Display can support up
to 75Hz refresh for some video modes. The video card of the connected PC must be
capable of supporting 75Hz. The preferred Mode is 1920 x 1080 @ 60 Hz.)
Resolutions supported 1920 x 1200 1920 x 1080 1680 x 1050
1600 x 900 1440 x 900 1280 x 1024 1280 x 800 1280 x 720 1024 x
768 800 x 600 720 x 480 640 x 480 Pixel pitch 0.27 mm
Brightness 300 cd/m˛ 1 Contrast ratio 1000:1 static 10000000:1
dynamic 1 View angle 178° horizontal 178° vertical Response time
5 ms gray to gray 1,3 Tilt and swivel angle Tilt: -5 to +22° Swivel:
ą45° Pivot rotation: 90° Height: 150 mm Display features Anti-glare
In plane switching Language selection LED Backlights On-screen controls
Pivot rotation Plug and Play User programmable Low Haze Physical
security Security lock-ready (lock is sold separately) VESA mount
100 mm Connectivity Input connector 1 DVI-D 1 HDMI
1.4 1 DisplayPort? 1.2 (with HDCP support on DisplayPort? and HDMI )
Ports 1 analog audio output 3 USB 3.0 (downstream) 1 USB 3.1 Type-C?
(side, downstream, power delivery up to 10 W) 1 USB 3.1 Type-C? (rear,
downstream and upstream, power delivery up to 15 W) 1 Dimensions and
weight Weight 7.2 kg (With stand) Product dimensions without
stand (W x D x H) 53.2 x 4.68 x 35.1 cm (Without stand) Dimensions
With Stand (W x D x H) 53.2 x 21.4 x 50.3 cm Power and operating
requirements Power supply Input voltage: 100 to 240 VAC
Power consumption 92 W (maximum) 40 W (typical) 0.5 W
(standby) Power consumption (on-mode) 36 W Power consumption
53 kWh Power consumption (standby) 0.5 W Power consumption
(off-mode) 0.3 W Operating temperature range 5 to 35°C Operating
humidity range 20 to 80% RH Energy efficiency class B
Environmental Arsenic-free display glass Mercury-free display
backlights Low halogen Energy Efficiency Energy
efficiency class B Display size (diagonal) 60.96 cm (24?)
Power consumption (on-mode) 36 W Power consumption 53 kWh
Power consumption (standby) 0.5 W Power consumption (off-mode) 0.3 W
Resolution (native) WUXGA (1920 x 1200 @ 60 Hz) Certification and
compliance Certifications and compliances BSMI CB CCC
CE CEL cTUVus CU ErP FCC ICES ISC ISO 9241-307
Mexico CoC Microsoft WHQL Certification (Windows 10 and Windows 7) MSIP
RCM SmartWay Transport Partnership - NA only VCCI WEEE
