Maximum Midband Output Power, 1 kHz, THD=1%:-into 2.66 Ohms 2 x 1350 Winto
4 Ohms 2 x 1000 Winto 8 Ohms 2 x 730 WMaximum Output Voltage of power
amplifi er, no load:70 VrmsTHD at 1kHz, MBW=80kHz:-MIC input to Main L/R output,
+16 dBu, typical:< 0.005%Power amplifier input to Speaker L/R output:<
0.01%DIM 30, power amplifier:< 0.01%IMD-SMPTE, power amplifier, 60Hz, 7
kHz:< 0.01%Frequency Response, -3dB ref. 1kHz::-Any input to any Mixer
output:15Hz ... 80kHzAny input to Speaker L/R output:20Hz ... 70kHzCrosstalk,
1kHz::-Fader and AUX-Send attenuation:> 85 dBChannel to channel:> 80
dBCMRR, MIC input, 1kHz:> 80 dBInput Sensitivity, all level controls in max.
position:-MIC input:-74 dBu (155 &#956;V)LINE Input (Mono):-54 dBu (1.55
mV)LINE Input (Stereo):-34 dBu (15.5 mV)Power Amplifier Input:+6 dBu (1.55
V)Maximum Level, mixing desk:-MIC inputs:+ 21 dBuMono Line inputs:+ 41 dBuStereo
Line inputs:+ 30 dBuAll other inputs:+ 22 dBuRecord Send output:+ 14 dBuAll
other outputs:+ 22 dBuInput Impedances:-MIC:2 k ohmsInsert Return:2.2 k ohmsEQ
Input and 2 Track Return:8 k ohmsAll other inputs:> 15 k ohmsOutput
Impedances:-Record Send:1 k ohmsPhones:47 ohmsAll other outputs:75
ohmsEquivalent Input Noise, MIC Input, A-weighted, 150 ohms:-130 dBuNoise,
Channel inputs to Main L/R outputs, A-weighted:-Master fader down:-95 dBuMaster
fader 0 dB, Channel fader down:-88 dBuMaster fader 0 dB, Channel fader 0 dB,
Channel gain unity:-82 dBuSignal/Noise-Ratio, power amplifi er, A-weighted:105
dBEqualization:-LO Shelving:&plusmn; 15 dB / 60 HzMID Peaking, mono
inputs:&plusmn; 15 dB / 100 Hz ... 8 kHzMID Peaking, stereo
inputs:&plusmn; 12 dB / 2.4 kHzHI Shelving:&plusmn; 15 dB / 12 kHzMaster
EQ, 2x7-band, 63, 125, 400, 1k, 2k5, 6k, 12k Hz:&plusmn; 10 dB / Q=2.0Power
Consumption at 1/8 maximum output power, 4 ohms:640 WDimensions, (WxHxD),
mm:673.5 x 210.5 x 504.5Weight, without lid / including lid:23.5 kg / 25 kg
